PVD coatings for tools, parts and components

PVD coatings: individual for your application

PVD coatings (Physical Vapor Deposition) have been established for years in almost all markets and industries to improve the durability and performance of tools and components of all kinds.

PVD coatings are created in a high vacuum by converting metal into a vaporous state and simultaneously adding a reaction gas. With different temperatures (from 200 ° C) we can deposit layers of 2-8 µm.

Our in-house research and development department has developed numerous successful PVD coatings in recent years and presented them to the market, which have always resulted from market and customer needs. With our many years of know-how and our proximity to our sister companies, we have a deep insight into the entire value chain, which extends from the material to the finished tool.

In the field of PVD coatings, we are one of the leading suppliers and service providers worldwide and can offer our services in numerous industries and segments.

Our product solutions are based on your needs and problems.

Get in touch with us now to find the right solution for you.

Your benefits at a glance

Combination with friction-reducing layers possible
variable layer structure (nanostructures, multilayer, monolayer)
chemical and mechanical decoating possible
very good adhesion to the substrate
very good impression of textured and polished surfaces
very good dimensional accuracy and contour accuracy
no hardness drop
no influence on the microstructure with suitable material selection

Overview of our product solutions

Do you already know which of our PVD coatings is suitable for your request or would you like to make a comparison between your previous service provider and us? Please get an overview of our products below.

Please do not hesitate to contact us if you have any questions or need advice. We take your individual application into account and work with you to find the best possible solution.

Overview of our product solutions

PVD coating	Hardness (HV)	max. application temperature (°C)	Friction coeff. against steel	Coating thicknesses (µm)	Colour	Applications	Further informations
CARBON-X^®	2,400 ± 400	325	0.05 – 0.15	1.5 – 2.5	black-gray	Machining Cutting / forming Plastic injection molding Components	Productinformation
CARBON-X^®-AL	2,400 ± 400	325	0.05 – 0.1	3 – 4	dark-grey	Forming	Productinformation
CHROME-X^®	1,400 – 2,200	400		1 – 3	silvery, shiny metallic	Plastic injection molding	Productinformation
CrN	2,000 ± 600	600	0.3 – 0.4	1 – 6	slate-grey	Machining Punching / forming Plastic injection molding	Productinformation
CrCN	2,300 ± 200	600	0.2 – 0.4	2 – 6	silver-grey	Machining Punching / forming Plastic injection molding	Productinformation
CrN Multilayer	2,000 ± 200	600	0.3 – 0.4	2 – 6	silver-grey	Plastic injection molding Punching / forming Magnesium die-casting	Productinformation
CROSAL^®-plus	3,200 ± 300	1.100	0.45	2 – 5	slate-grey	Machining Punching / forming	Productinformation
DUMATIC^®	3,700 ± 500 Toplayer 2,600 ± 300 Layer composite	400	0.25	3 – 5	red/grey	Punching / forming	Productinformation
Duplex-VARIANTIC^®	3,500 ± 500	800	0.2	4 – 6	dusky-pink	Forming Punching	Productinformation
Duplex-VARIANTIC^®-1000	4,000 ± 200	800	0.6 – 0.7	8 – 9	dark red-gold	Forming	Productinformation
EXXTRAL^®	3,300 ± 300	800	0.7	2 – 5	anthrazit	Machining Punching / forming Plastic injection molding	Productinformation
EXXTRAL^®-plus	3,300 ± 300	800	0.7	2 – 5	anthrazit	Machining Punching / forming Plastic injection molding	Productinformation
EXXTRAL^®-silver	3,300 ± 300	800	0.4	2 – 4	silver	Machining Forming	Productinformation
EXXTRAL^®-ultrafine	3,300 ± 300	800		2 – 3	anthrazit	Machining	Productinformation
MoX2^®	< 500	400	0.1	1	anthrazit	Machining Forming / cutting tools	Productinformation
SISTRAL^®	2,500 ± 300	900	0.7	1 – 4	anthrazit	Machining Punching	Productinformation
SISTRAL^®-plus	2,800 ± 300	900	0.7 – 0.8	2 – 4	petrol	Machining Hard machining	Productinformation
SISTRAL^®-ultrafine	2,500 ± 300	900		2 – 3	anthrazit-blue	Machining	Productinformation
SISTRAL^®-Gold	3,000 ± 500	900	0.6	1 – 4	gold	Machining	Productinformation
SUBLIME^®	3,300 ± 200	1,100	0.7 – 0.8	2 – 4	grey	Gear manufacturing	Productinformation
SUCASLIDE®	1,000 – 1.200	400	0.05 – 0.1	1.5 – 2.5	black	Punching / forming Machining Plastic injection molding Components	Productinformation
SUPRAL	3,500 ± 500	800	< 0.5	2 – 5	black	Machining Punching	Productinformation
TiCN	3,500 ± 500	400	0.2	1 – 4	blue-gray	Machining Punching / forming Plastic injection molding	Productinformation
TiCN-ultrafine	3,500 ± 500	400		1 – 4	anthrazit-blue	Machining Forming	Productinformation
TIGRAL^®	3,300 ± 300	900	0.6	1 – 4	dark-grey	Punching / forming Die-cast aluminum	Productinformation
TiN	2,300 ± 300	500	0.6	1 – 4	gold	Machining Punching / forming Plastic injection molding	Productinformation
TiN-ultrafine	2,800 ± 150	500		2 – 4	gold	Machining Punching / forming Plastic injection molding	Productinformation
TOPMATIC^®	2,800 ± 300	700	0.6	5 – 10	aubergine	Forming / cutting	Productinformation
VARIANTIC^®	3,500 ± 500	800	0.2	2 – 4	dusky-pink	Machining Punching / forming	Productinformation
ZrCN	3,100 ± 300	600	0.5	1 – 4	brown-silver	Machining Punching / forming	Productinformation
ZrN	2,800 ± 300	600	0.5	1 – 4	light-yellow	Machining Punching / forming	Productinformation

*further adjustments of the coating thickness possible on request
